PRODUCT OVERVIEW

AKG SR4500 BD3 - WMS4500 series analog wireless receiver (650-680 MHz), power supply not included. The receiver uses the Diversity system for preventing loss of communication between the transmitter and receiver, and has a durable shielding metal case; Each receiver has the ability to retune within the UHF band with a width of 30 MHz. The total number of operating frequencies that are available for tuning in each of the six available ranges is 1200; A preliminary test signal allows to obtain information on the status of the transmitter on the receiver’s display screen in silent mode until it is fully activated (position of the Mute switch, battery charge level, the frequency at which the transmitter is tuned); It is possible to remotely control the receiver from a computer, which is especially true for a large complex of systems, and also provides a logic output for controlling external devices, such as an automatic mixer; Functions Auto Setup, Environment Scan and Rehearsal (function "rehearsal"); All information in the form of luminous numbers and symbols is reflected on the large display of the receiver or on the computer monitor, parameters are controlled and information is called up using the wheel - Jog wee.

Key features of the AKG SR4500 BD3:

• diversity receiver in a metal case;
• Auto-tuning, scanning of the environment and rehearsal functions for ease of setup; the use of
• several frequency ranges ensures the operation of up to 70 channels at the same time;
• An integrated data interface for controlling and monitoring from a computer using the PO System  Architect
• monitoring of the battery status of the transmitter and the tone code of the silent tuning;
• available in eight UHF bands, each 30 MHz wide, with 1200 selectable frequencies;
• programmable color display with background illumination and scroll wheel for ease of use;
• an exit for management of the external devices.
