Dahua LS550UEM-EF 55 Inch FHD 1080P 0.88mm Ultra Narrow Bezel ADS Video Wall Display
Key Features:
-
Designed for 24/7 continuous professional use with industrial-grade reliability
-
High-resolution display support delivering sharp, detailed and vivid image output
-
Wide viewing angle IPS technology for consistent clarity from all directions
-
Multiple input interfaces (HDMI/DP/VGA depending on configuration) for flexible connectivity
-
Slim bezel, anti-glare screen design with optimized visual comfort and reduced reflections
PRODUCT OVERVIEW
Professional Display Solution
The Dahua commercial display is designed for professional environments where reliable, continuous visual performance is required. It is commonly used in control rooms, retail signage, and corporate communication systems. Built with industrial-grade components, it focuses on durability and stable long-term operation. The display supports both landscape and portrait installation modes for flexible deployment scenarios.
Display Technology and Image Quality
This product features an A+ grade LCD panel with Full HD or higher resolution depending on the variant. It delivers sharp image clarity with consistent color reproduction and wide viewing angles up to 178° horizontally and vertically. The anti-glare surface enhances visibility in bright environments, making it suitable for public-facing installations. High brightness options ensure clear visuals even under challenging lighting conditions.
Performance and System Integration
The display is powered by an embedded Android-based system that supports multimedia playback, scheduling, and remote content management. It includes built-in decoding capabilities for video streams, enabling direct playback without external devices. Network connectivity through wired LAN and Wi-Fi allows seamless integration into digital signage ecosystems. This makes it highly efficient for centralized content control across multiple screens.
Design, Build Quality, and Installation
Dahua has engineered this display with a slim bezel design and a full metal casing to ensure both aesthetics and durability. The tempered protective glass adds an extra layer of safety for public environments. Its modular structure allows for flexible installation on walls or custom mounting setups. The design also emphasizes thermal efficiency, enabling stable operation during extended usage periods.
Applications and Use Cases
| Product Name | Dahua LS550UEM-EF 55 Inch FHD 1080P 0.88mm Ultra Narrow Bezel ADS Video Wall Display |
|---|---|
| Weight | 24.100000 |
| Screen Size | 55" |
| Screen Size | 55" |
| Contrast Ratio | 1200:1 |
| Resolutions | 1920×1080 (FHD) |
| Response Time | 8ms |
| Power Consumption | 166W |
| Max. Power Consumption | 180W |
| Standby Power Consumption | <0.5W |
| Display Colors | 8bit (16.7M) |
| Dimensions | 1210.5mm×681.3mm×115.8mm (47.7"×26.8"×4.6") |
| Package Weight | 33.9 kg |
| Packaging Dimensions | 1360mm×945mm×280mm (53.5"×37.2"×11.0") |
| Resolution | 1920x1080 (Full HD) |
| Brightness | 500 cd/m² |
| Backlight Adjustable | Direct LED |
| Built-In Speakers | Yes |
| Bezel Width | B2B: 1.74mm (Panel Bezel to Panel Bezel), 1.3mm (T/L), 0.44mm (B/R) A2A: 2.49mm (Active area to Active area), 1.74mm (T/L), 0.75mm (B/R) |
| Contrast Ratio | 1200:1 |
| Manufacturer | Dahua |
| Color | Black |
| Country of Origin | China |
Product Datasheet
