DMInteract DM-6040BS 60×40cm Tunnel, 38mm Penetration X-Ray Baggage & Parcel Scanner
Key Features Of DMInteract DM-6040BS
- Explosives & narcotics detection
- Colour-coded material identification
- 64× continuous image zoom
- 50,000-image archive
- Threat Image Projection (TIP)
Advanced Security Screening with the DM-6040BS
The DMInteract DM-6040BS X-Ray Baggage Scanner is designed for the inspection of hand baggage, parcels and other items at security checkpoints. Its 60 cm × 40 cm tunnel class, 160 kV X-ray generator, high-resolution imaging and automated suspicious-item alerts support efficient security screening in demanding environments.
Reliable Screening with Intelligent Imaging
Built for security checkpoints that need clear X-ray images, consistent throughput and practical operator-assistance functions, the DM-6040BS combines advanced image processing with a durable conveyor system.
High-Penetration Imaging
A 160 kV X-ray generator and guaranteed 38 mm steel penetration help operators inspect baggage contents and view concealed objects.
Advanced Image Enhancement
Image enhancement, variable contrast, edge enhancement and up to 64× continuous zoom help operators examine image details.
Suspicious-Item Alerts
Automated alarms and box-line marking identify suspicious objects and items that may be difficult to penetrate with X-rays.
Material Classification
Colour-coded imaging and organic or inorganic material stripping help operators differentiate material categories during inspection.
Bidirectional Conveyor
Forward and reverse conveyor operation supports flexible inspection workflows, with a conveyor speed of 0.22 m/s.
Built-In Diagnostics
Power-on self-testing, system diagnostics, system logs and user management support routine operation and troubleshooting.
Professional Baggage and Parcel Screening
The DMInteract DM-6040BS is an X-ray baggage inspection system developed for security screening of hand luggage, parcels and other suitable items. Its 613 mm × 409.5 mm tunnel, high-resolution detector array and 160 kV X-ray generator provide imaging capabilities for security inspection operations.
With colour and black-and-white imaging, variable contrast, local enhancement and high- or low-penetration image processing, operators can adjust the display to examine objects of interest. The system also supports image archiving, image search and USB export for operational review.
DMInteract DM-6040BS Security Screening System
Enhanced Image Analysis and Operator Assistance
The DM-6040BS imaging system provides colour and monochrome display modes, organic and inorganic stripping, reverse colour, edge enhancement, pseudo-colour imaging and continuous zoom up to 64×. These tools help operators examine image details and interpret baggage contents.
The system can highlight suspicious organic materials associated with effective atomic numbers 7, 8 and 9. Automated suspicious-item alarms, object marking and Threat Image Projection (TIP) provide additional operator-assistance and training functions. These features support screening decisions but do not replace trained operator assessment.
Illustrative X-ray imaging and material classification
Durable Construction and Efficient Performance
The DM-6040BS features a robust frame constructed using 304 stainless steel, cold-rolled steel plate and square steel components. Its conveyor supports a maximum load of 150 kg, making the system suitable for handling a variety of baggage and parcel sizes within the specified tunnel dimensions.
Maximum power consumption is 0.8 kW, and operating noise is specified at less than 60 dB. Built-in diagnostics, a specially designed operator keyboard, image retrieval and system-management functions help support routine security screening workflows.
Scanner construction and conveyor inspection area
Key Features of the DM-6040BS
Advanced X-ray imaging, automated operator alerts, flexible image analysis and practical system management in one baggage inspection solution.
60 cm × 40 cm Tunnel Class
Designed for screening hand baggage, parcels and suitable items that fit within the specified tunnel opening.
160 kV X-Ray Generator
Single X-ray generator with upward beam direction, sealed oil cooling and a 100% duty-cycle specification.
38 mm Steel Penetration
Guaranteed steel penetration with AWG40 guaranteed wire resolution and AWG34 penetration resolution.
64× Continuous Zoom
Magnify image details with adjustable contrast, brightness, edge enhancement and other image-processing functions.
Suspicious-Item Alarm
Alarm and box-line marking functions assist operators in identifying suspicious objects during screening.
Organic Material Highlighting
Highlights suspicious organic materials associated with effective atomic numbers 7, 8 and 9.
50,000-Image Archive
Automatically stores up to 50,000 images and supports USB export to JPG, BMP and other supported formats.
Forward and Reverse Scanning
Bidirectional conveyor operation and forced-scanning functions provide additional workflow flexibility.
Full HD Operator Monitor
Includes a 21.5-inch LCD monitor with a 1920 × 1080 resolution, Intel Core i3 CPU and 1 TB storage.
Threat Image Projection
Inserts fictional threat images during screening to support operator vigilance, training and image-identification assessment.
Automatic Self-Diagnostics
Power-on self-tests, built-in diagnostics, system logs and user-management functions support operational monitoring.
Low Power Consumption
Maximum power consumption of 0.8 kW supports energy-conscious operation.
DM-6040BS Technical Specifications
Detailed physical, electrical, imaging and operating specifications for equipment planning and technical evaluation.
Physical Specifications
| Model | DM-6040BS |
| Product Type | X-Ray Baggage Scanner |
| Tunnel Size | 613 mm (W) × 409.5 mm (H) |
| Unit Dimensions | 2007 mm (L) × 844 mm (W) × 1234 mm (H) |
| Unit Weight | 455 kg |
| Gross Packed Weight | 500 kg |
| Packing Dimensions — Package 1 | 220 × 101 × 156 cm |
| Packing Dimensions — Package 2 | 120 × 65 × 100 cm |
| Frame Construction | 304 stainless steel, 2–5 mm cold-rolled steel plate and square steel components |
General and Conveyor Specifications
| Conveyor Speed | 0.22 m/s, forward or backward |
| Conveyor Height | 663.5 mm |
| Maximum Conveyor Load | 150 kg |
| Steel Penetration | 38 mm guaranteed |
| Wire Resolution | AWG40 guaranteed |
| Penetration Resolution | AWG34 guaranteed |
| Spatial Resolution | 1.0 mm horizontal, 1.0 mm vertical |
| X-Ray Dose per Inspection | ≤ 4 µSv |
| X-Ray Leakage | ≤ 1 µSv/h at any point 5 cm outside the external surface; stated FDA limit ≤ 5 µSv/h |
| Film Safety | Guaranteed for ASA/ISO 1600 film |
| Maximum Power Consumption | 0.8 kW |
| Operating Noise | < 60 dB |
X-Ray Generator
| Generator Configuration | Single X-ray generator |
| Anode Voltage | 160 kV |
| Beam Direction | Upward |
| Cooling Method | Sealed oil cooling |
| Duty Cycle | 100% |
Imaging and Detection System
| Detector | 1152-channel L-shaped array |
| Image Modes | Colour and black-and-white imaging |
| Image Enhancement | Local enhancement, super enhancement, edge enhancement, variable contrast, brightness adjustment and reverse colour |
| Penetration Modes | High- and low-penetration imaging |
| Material Processing | Organic and inorganic stripping, pseudo-colour imaging and organics enhancement |
| Continuous Zoom | Up to 64× |
| Suspicious-Item Alarm | Alarm and box-line marking of suspicious objects, including difficult-to-penetrate materials, explosives and drugs |
| Organic Material Highlighting | Effective atomic numbers 7, 8 and 9 |
| Threat Image Projection | Fictional threat-image insertion for operator vigilance, training and image-identification assessment |
| Image Pullback | 30 images |
| Image Archive | Up to 50,000 images; automatic storage and USB export |
| Export Formats | JPG, BMP and other supported formats |
Computer and Operator Console
| Monitor | 21.5-inch LCD |
| Display Resolution | 1920 × 1080 Full HD |
| CPU | Intel Core i3, 3.3 GHz |
| Memory | 4 GB RAM |
| Storage | 1 TB |
| Operating System | Windows 10, as specified |
| Console | One console with specially designed keyboard |
| Electric Roller | Three-phase |
Operating Environment and Power
| Operating Temperature | 5 °C to 40 °C |
| Operating Humidity | 0–90%, non-condensing |
| Storage Temperature | −20 °C to 60 °C |
| Storage Humidity | 10–90%, non-condensing |
| Standard Operating Power | 220 V (+10% / −15%), 50 ± 3 Hz |
| Optional Power Configuration | 110–120 V or 230–240 V, 60 Hz options |
System Functions and Optional Accessories
| System Functions | Date/time display, counters, user management, system-on and X-ray-on timers, power-on self-test, built-in diagnostics, bidirectional scanning, forced scanning, image search and export, system settings, system log, standby and simulation training |
| Optional Accessories | UPS, additional roller table, intelligent roller with bag sensing, remote workstation, network integration and video monitoring |
Suitable for Security Screening Environments
Designed for suitable baggage and parcel inspection workflows in facilities requiring systematic X-ray security screening.
DMInteract Product
A security screening solution presented under the DMInteract brand, identified as a Proud Canadian Brand.
Detailed Technical Capabilities
Comprehensive imaging, penetration, conveyor, environmental and system specifications for technical evaluation.
Configurable System Options
Optional accessories include UPS, roller tables, remote workstations, network integration and video monitoring.
Upgrade Your Screening with the DM-6040BS
Explore the DMInteract DM-6040BS X-Ray Baggage Scanner for your security inspection requirements. Review the tunnel dimensions, penetration specifications, conveyor capacity, electrical configuration and optional accessories before finalising your installation.
```
| Product Name | DMInteract DM-6040BS 60×40cm Tunnel, 38mm Penetration X-Ray Baggage & Parcel Scanner |
|---|---|
| Tunnel Size | 613 × 409.5 mm |
| Steel Penetration | 38 mm |
| Wire Resolution | AWG40 |
| Conveyor Load Capacity | 150 kg |
| X-Ray Generator Voltage | 160 kV |
| Conveyor Speed | 0.22 m/s |
| X-Ray Dose | ≤4 µSv |
| X-Ray Leakage | ≤1 µSv/h |
| Penetration Resolution | AWG34 |
| Detector | 1152-Channel L-Shaped Array |
| Monitor | 21.5" |
| Explosives & Narcotics Detection | Yes |
| TIP | Yes |
| CPU | Intel i3, 3.3 GHz |
| Weight | 1.000000 |
| Color | Black |
