Eaton 9PX2200IRT2U 2.2 kVA / 2.2 kW Double-Conversion Rack/Tower UPS
The Eaton 9PXEBM72RT3U is a dedicated extended battery module (EBM) designed to significantly increase the backup runtime of Eaton 9PX series UPS units, especially 2.2 kVA and 3 kVA rack/tower models. By integrating additional battery capacity, this module enables extended autonomy during mains power outages, giving IT administrators and facilities more time to safeguard systems and execute orderly shutdown or fail‑over procedures.
PRODUCT OVERVIEW
Eaton 9PXEBM72RT3U—Extended Battery Module for 9PX UPS Systems
The Eaton 9PXEBM72RT3U is a dedicated extended battery module (EBM) designed to significantly increase the backup runtime of Eaton 9PX series UPS units, especially 2.2 kVA and 3 kVA rack/tower models. By integrating additional battery capacity, this module enables extended autonomy during mains power outages, giving IT administrators and facilities more time to safeguard systems and execute orderly shutdown or fail‑over procedures.
Battery Capacity & Configuration
This module houses 12 sealed lead‑acid batteries rated at 12 V / 9 Ah, which together give the unit a 72 V battery string suitable for 9PX UPS systems. The sealed VRLA battery design is maintenance‑free and reliable, supporting long‑term use and dependable performance in power critical environments such as server rooms and edge data closets.
Application & Benefits
Adding the Eaton 9PXEBM72RT3U to your UPS setup extends the period for which critical loads remain powered during outages—an essential advantage for server racks, network closets, telecommunications equipment, and edge IT infrastructure where uptime matters. Multiple EBMs can be connected in parallel with a UPS to further increase runtime based on operational needs, offering scalable power continuity without upgrading to a larger UPS unit.
Key Benefits:
-
Extended runtime for critical systems during utility failures
-
Rack/tower design with included mounting kit
-
Maintenance‑free VRLA battery technology
-
Scalable solution when paired with compatible Eaton 9PX UPS models
-
Certified to global safety, EMC, and performance standards
| Product Name | Eaton 9PX2200IRT2U 2.2 kVA / 2.2 kW Double-Conversion Rack/Tower UPS |
|---|---|
| Output Power | 2.2KVA/ 2200VA |
| Output Voltage | 230 Volts |
| Input Frequency | 50/60 Hz |
| Input Voltage Range | 176–276 V (100–276 V with derating) |
| Interface Ports | Contact Closure, LCD, RS-232, USB |
| Control Panel | LCD display (status/measurements) |
| Battery Type | Sealed lead‑acid (VRLA) 6 × 12 V / 7 Ah |
| Recharge Time | Not specified in Eaton official specs (exact hours not published) |
| Audible Alarm | 6 × 12 V / 7 Ah |
| Approvals | CE, IEC/EN 62040-1/2, UL 1778, cULus, CSA 22.2, FCC Class B, CISPR22 Class B, ENERGY STAR, EAC |
| Dimensions | 440 mm × 605 mm × 86.5 mm |
| Weight | 28.000000 |
| Manufacturer | Eaton |
| Color | Black |
