Print Method

Thermal Transfer / Direct Thermal

Resolution

203 dpi (8 dots/mm)

Print Speed

5IPS (127 mm/s)

Print Width

2.12" (54mm)

Print Length

Min. 0.16” (4 mm); Max. 68” (1727 mm)

Processor

32 Bit RISC CPU

Memory

8MB Flash (4MB for user storage) / 16MB SDRAM

Sensor Type

Fixed transmissive sensor and reflective sensor, central aligned
Adjustable reflective sensor (full range)

Media

Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width: 0.6” (15 mm) Min. - 2.36” (60 mm) Max.
Thickness: 0.003” (0.06 mm) Min. - 0.008” (0.20 mm) Max.
Label roll diameter: Max. 5” (127 mm)
Core diameter: 1”, 1.5” (25,4 mm, 38,1 mm)

Ribbon

Types: Wax, wax/resin, resin
Length: 360’ (110 m)
Width: 2.20” (56mm) - 2.32” (59mm)
Ribbon roll diameter.: 1.57“ (40 mm)
Core diameter: 0.5” (12.7 mm)

Printer Language

EZPL, GEPL, GZPL auto switch

Software

Label design software: GoLabel (for EZPL only)
Driver & DLL: Windows 2000, XP, Vista, 7, 8,Windows Server 2003 & 2008

Resident Fonts

Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable

Download Fonts

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable

Barcodes

1-D Bar codes:
Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128, UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, HIBC, MSI (1 Mod 10), Random Weight, Telepen, FIM, China Postal Code, RPS 128 and GS1 DataBar
2-D Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, Aztec code

Code Pages

CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
Unicode (UTF8, UTF16)

Graphics

Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software

Interfaces

USB 2.0
Serial port: RS-232 (DB-9)
Ethernet 10/100 Mbps

Control Panel

Two LEDs: Ready, Status
Control Key: FEED
Power on/off button
Calibration button

Real Time Clock

Standard

Power

Auto Switching 100-240VAC, 50-60Hz

Environment

Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C)

Humidity

Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing.

Agency Approvals

CE(EMC), FCC Class A, CB, CCC, cUL

Dimension

Length: 9.7” (254 mm)
Height: 6.9” (175 mm)
Width: 5.3” (136 mm)

Weight

4 lbs (1.8 Kg) ,excluding consumables

Options

Guillotine Cutter
Label Dispenser
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder
