GW INSTEK GPC-3060D Triple Output Linear D.C. Power Supply
Actual Stock Can Be Confirmed After Placing the Order.
SKU
GPC-3060D
Pay 4 interest-free payments of AED 421.00.Learn more
The SPD-3606 DC power supply provides 375W output capacity, three isolated outputs with dual-range for CH1 & CH2, highly efficient power conversion, low noise, high reliability, thorough protection,excellent value, and a compact size.
PRODUCT OVERVIEW
The GPC-Series is triple output, 375W, linear DC power supplies. Channel 1 and 2 are fully adjustable (model dependant) and Channel 3 is fixed at 5V/3A with ripple and noise at less than 2mVrms. Overload and reverse polarity protection keep GPC-Series and its loads safe from unexpected conditions. The GPC features continuous or dynamic internal load selection and serial or parallel tracking for application flexibility.The GPC-Series is an ideal solution for inexpensive bench-top applications requiring low noise and multiple outputs.
Features
- Triple Output
- Auto Tracking
- Auto Series and Parallel Operation
- Constant Voltage and Constant Current Operation
- Low Ripple and Noise
- Internal Select for Continuous or Dynamic Load
- Overload and Reverse Polarity Protection
- 3 1/2 Digits 0.5" LED Display
- 5V, 3A Fixed Output
- (Note: GPC-3060D/6030D are not CE approved)
| Product Name | GW INSTEK GPC-3060D Triple Output Linear D.C. Power Supply |
|---|---|
| Weight | 18.46 Kg |
| Power Supply (PoE) | (0 ~ 30V/0 ~ 6A) x 2 , (5V/3A MAX) x 1 |
| Max. Power Consumption | 375W |
| Power Method | AC 100V/120V/220V/240V 10%, 50/60Hz |
| Dimensions | 255(W) x 145(H) x 346(D) mm |
| Manufacturer | GW INSTEK |
| Color | Black |
| Country of Origin | United States |
