JBL SUB 18H Horn Loaded Active Subwoofer (Single)
JBL introduces its most powerful studio subwoofer for applications in which very high continuous output and extreme low frequency response is required. With in-room response below 18Hz and 137 dB peak output, the SUB18.
PRODUCT OVERVIEW
JBL's most powerful studio subwoofer with very high continuous output and extreme low frequency response.
JBL introduces its most powerful studio subwoofer for applications in which very high continuous output and extreme low frequency response is required. With in-room response below 18Hz and 137 dB peak output, the SUB18 delivers unprecedented performance for demanding dance music production, while providing exceptional accuracy required in cinema post production applications. As an add-on to JBL’s M2 Master Reference Monitor system, the SUB18 allows three times greater output from the system.
As an add-on to JBL’s M2 Master Reference Monitor system, the SUB18 allows three times greater output from the system.
| Product Name | JBL SUB 18H Horn Loaded Active Subwoofer (Single) |
|---|---|
| Weight | 45.000000 |
| Frequency Response | -6 dB (4π measurement): 23.1 Hz. |
| Frequency Range | Frequency Response, -10 dB (4π measurement) 20.6 Hz Frequency Response, -6 dB (4π measurement) 23.1 Hz |
| Power Capacity | 3,500 to 4,000W into 8Ω |
| Maximum SPL | 137 dB SPL |
| Impedance | 8Ω |
| Sensitivity (SPL / 1 W @ 1 m) | 92dB @ 1m, 2.83 V |
| Enclosure | 18mm 11-ply Baltic Birch Plywood |
| Dimensions | 27 x 30 x 24 inches (685 x 762 x 620 mm) |
| Color | Black |
| Country of Origin | United States |
Product Datasheet
