LD Systems VA 8 Dual 8" 150W Line Array Speaker
The LD Systems VA4 is a lightweight, ultra compact 2 x 4" line array speaker cabinet for configurations with an 80Hz - 19kHz frequency response. The dual 4" woofers with high efficiency neodymium magnets and Kevlar cones have a power handling capacity of 200W continuous.
PRODUCT OVERVIEW
LD Premium VA8 Line Array
The LD Systems VA8 Array is a 2 x 8" line array speaker with a transparent sound that is especially suitable for medium to large configurations with a frequency range of 70 Hz - 19 kHz.
This dual speaker system contains one high-efficiency neodymium bass speaker on each side with a power rating of 500 W (continuous). The two neodymium HF drivers with a 1.35" voice coil and protection circuit connected to 1" wave guides are designed
to handle maximum outputs of 150 W (continuous). The individual elements are capable of covering an area of 120° x 10° with an extensive frequency range.
The cabinet of the VA8 is made of 15 mm birch plywood and coated with a durable, waterproof Dura-Coat LX finish. Each cabinet has Neutrik NL-4 connectors and flying points and can be set to angles between 0° and 6° in 1° increments. Thus, the VA8
can be both flown and used as a ground stack.
For example, the dual-loaded 18" V218B subwoofer or the 2 x 15” bass-reflex V215B subwoofer are ideal expansions for the low bass range. On our website, you will find corresponding EASE GLL files and controller setups for the LD Systems DPA260
speaker processor for optimal array planning and trouble-free installation.
| Product Name | LD Systems VA 8 Dual 8" 150W Line Array Speaker |
|---|---|
| Weight | 27.50 Kg |
| Frequency Response | 70 - 19000 Hz |
| Power Capacity | 150 W |
| Maximum SPL | 113 dB |
| Impedance | 16 Ohm(s) |
| Dimensions | W 740 mm * H 247 mm * D 467 mm |
| Manufacturer | LD Systems |
| Color | Black |
| Country of Origin | United States |
