• Supports 7th / 6th Gen Intel Core / Pentium / Celeronprocessors for LGA 1151 socket


• Supports DDR4-2400 Memory (Max.)
  DDR4 Boost: Give your DDR4 memory a performance boost


• Audio Boost: Reward your ears with studio grade sound quality for a HI-FI experience


• EZ Debug LED: Easiest way to troubleshoot
  Turbo M.2: Delivering Speeds Up to 32Gb/s, Intel Optane Memory Ready

  X-Boost: Great tool to boost your USB & Storage performance
  Doublo ESD Protection: Double layer grounding motherboard mounting holes


• Military Class 5, Guard-Pro: Latest evolution in high quality components for best protection and efficiency


• Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites and search function

Specifications:

CPU

• Supports 7th/6th Gen Intel® Core i3/i5/i7 processors, and Intel®Pentium and Celeron processors for Socket LGA1151.

Chipset

• Intel H270 Chipset

Main Memory

• 4 x DDR4 memory slots, support up to 64GB
• 7th Gen processors support DDR4 2400/ 2133 MHz
• 6th Gen processors support DDR4 2133 MHz
• Dual channel memory architecture
• Supports Intel Extreme Memory Profile (XMP)

Slots

•  2 x PCIe 3.0 x16 slots (support x16/x4 mode)
•  4 x PCIe 3.0 x1 slots

Multi-GPU

• • Supports 2-Way AMD CrossFire Technology

Onboard Graphics

•  1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz


•  1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz


•  1 x DisplayPort, supports a maximum resolution of 4096x2304@24Hz, 2560x1600@60Hz, 3840x2160@60Hz, 1920x1200@60Hz

Storage

•  Intel H270 Chipse
•  6 x SATA 6Gb/s ports
•  1 x M.2 slot (Key M)
•  Support up to PCIe 3.0 x4 and SATA 6Gb/s
•  Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host Card
•  Supports 2242/ 2260 /2280/ 22110 storage devices
•  Intel Optane Memory Read
•  Supports Intel Smart Response Technology for Intel Core processors

RAID

•  Intel H270 Chipset
•  Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

USB

•  Intel H270 Chipset
  8 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)


•  6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)

Audio

•  Realtek ALC892 Codec
   7.1-Channel High Definition Audio

LAN

• 1 x Realtek RTL8111H Gigabit LAN controller

  Internal I/O Connectors

- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x Clear CMOS jumper

Back Panel I/O Ports

- 1 x PS/2 mouse & keyboard combo port
- 4 x USB 3.1 Gen1 Type-A ports
- 1 x VGA port
- 1 x DVI-D port
- 1 x DisplayPort
- 1 x LAN (RJ45) port
- 2 x USB 2.0 ports
- 6 x audio jacks

Dimension

•  12.0 in. x 8.9 in. (30.5 cm x 22.5 cm)
•  ATX Form Factor

Mounting

• • 9 mounting holes
