• Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket

  Supports DDR4 Memory, up to 2666 MHz

  MYSTIC LIGHT and Sync: Personalize your PC with 16.8 million colors / 10 effects controlled in one click with the Mystic Light APP or a mobile device.

  Lightning Fast Game experience: TURBO M.2, Intel Optane Memory Ready. Intel Turbo USB 3.1 GEN2

  AUDIO BOOST with NAHIMIC: Reward your ears with studio grade sound quality for the most immersive gaming experience

  DDR4 Boost: Advanced technology to deliver pure data signals for the best gaming performance and stability.

  GAMING LAN, powered by Intel: The best online gaming experience with lowest latency and bandwidth management.

  MULTI-GPU: With STEEL ARMOR PCI-E slots. Supports 2-Way AMD Crossfire

  VR Ready: Best virtual reality game experience without latency, reduces motion sickness.

  In-Game Weapons: GAMING Hotkey, X-Boost, Voice Boost.
  EZ Debug LED: Easiest way to troubleshoot.

  Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites and search function.

  GAMING CERTIFIED: 24-hour on- and offline game and motherboard testing by eSports players.

Specifications:

PROCESSOR
Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket

CHIPSET
Intel B360 Chipset

MEMORY
4 x DDR4 memory slots, support up to 64GB
Supports DDR4 2666/ 2400/ 2133 MHz1
Dual channel memory architecture
Supports non-ECC UDIMM memorye
Supports Intel® Extreme Memory Profile (XMP)

SLOTS
2 x PCIe 3.0 x16 slots (support x16/x4 modes)
4 x PCIe 3.0 x1 slots
ONBOARD GRAPHICS
1 x DisplayPort 1.2, supports a maximum resolution of 4096x2304 @ 60Hz
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
*No Display support when using the Processor model with suffix “F”

STORAGE
Intel B360 Chipset
5 x SATA 6Gb/s ports1
1 x M.2 slots (Key M)
Support up to PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260 /2280/ 22110 storage devices
Supports Intel® Optane™ Memory Ready2
The SATA1 connector will be unavailable when an M.2 SATA SSD module has been installed in the M.2_1 slot.Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

USB
Intel B360 Chipset
2 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the back panel)
4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the back panel, 2 ports available through the internal USB connectors)
6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)

AUDIO
Dual Realtek ALC892 Codec
7.1-Channel High Definition Audio

LAN
1 x Intel I219-V Gigabit LAN controller

INTERNAL CONNECTORS
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 6-pin ATX PCIe power connector
5 x SATA 6Gb/s connectors
1 x USB 3.1 Gen1 connectors (supports additional 2 USB 3.1 Gen1 ports)
2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1 x 4-pin CPU fan connector
1 x 4-pin water pump fan connector
5 x 4-pin system fan connectors
1 x Front panel audio connector
2 x Front panel connectors
1 x Series port connector
1 x Parallel port connector
1 x 5050 RGB LED strip 12V connector
1 x TPM module connector
1 x Thunderbolt Add-on Card Connector
1 x Chassis Intrusion connector
1 x Clear CMOS jumper
