• Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket


• Supports DDR4 Memory, up to 2666 MHz


• Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs


• Extended Heatsink Design: MSI extended PWM and enhanced circuit design ensures even high-end processors to run in full speed.


• Core Boost: With premium layout optimized power design to support more cores and provide better performance.


• DDR4 Boost: Advanced technology to deliver pure data signals for the best gaming performance and stability.


• Audio Boost: Reward your ears with studio grade sound quality for the most immersive audio experience


• PCI-E Steel Armor: Protecting VGA cards against bending and EMI


• X-Boost: Software that auto-detects and allows you to boost the performance of any storage, Optane or USB device


• EZ Debug LED: Easiest way to troubleshot

Specification:

PROCESSOR
Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket

CHIPSET
Intel B360 Chipset

MEMORY
4 x DDR4 memory slots, support up to 64GB
Supports DDR4 2666/ 2400/ 2133 MHz1
Dual channel memory architecture
Supports non-ECC UDIMM memorye
Supports Intel Extreme Memory Profile (XMP)

SLOTS
1 x PCIe 3.0 x16 slot
2 x PCIe 3.0 x1 slots
ONBOARD GRAPHICS
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz
*No Display support when using the Processor model with suffix “F”

STORAGE
Intel B360 Chipset
6 x SATA 6Gb/s ports1
1 x M.2 slots (Key M)
Support up to PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260 /2280/ 22110 storage devices
Intel Optane Memory Ready2
The SATA1 connector will be unavailable when a SATA M.2 SSD has been installed in the M.2_1 slot.Before using Intel Optane memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

USB
Intel B360 Chipset
6 x USB 3.1 Gen1 (SuperSpeed USB) ports (3 Type-A & 1 Type-C ports on the back panel, 2 ports available through the internal USB connector)
6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)

AUDIO
Dual Realtek® ALC887 Codec
7.1-Channel High Definition Audio

LAN
1 x Realtek 8111H Gigabit LAN controller

INTERNAL CONNECTORS
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
6 x SATA 6Gb/s connectors
1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1 x 4-pin CPU fan connector
2 x 4-pin system fan connectors
1 x Front panel audio connector
1 x Parallel port connector
1 x Serial port connector
2 x Front panel connectors
1 x TPM module connector
1 x Chassis Intrusion connector
1 x Thunderbolt add-on card connector
1 x RGB LED connector
1 x Clear CMO
