• Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket


• EZ Debug LED: Onboard LEDs for key components will indicate the source of the problem.


• Mining Guard: Power/Reset/Clear CMOS Buttons on Board for managing your mining board without screen on


• Intel LAN: Premium network solution from Intel for professional and multimedia use. Delivers a secure, stable and fast network connection.


• Mining Management: MSI mining motherboard featuring customized Mining BIOS and built-in slot detection. Auto detect your PCIE slot status and manage your mining rig with just one glance

  Diskless Boot Supports: With diskless boot environment, miners don’t need maintain the operation system for each mining machines and save the money from the hard drives.


• Mining LED: Featuring mining LED for each PCIE slot on the mining motherboard, you can check the status for each GPU by only spot the motherboard.


• Super Mining Machine: Support 13X graphic cards for more hash. Give you the easiest and the most convenient solution for your mining rig.


• Independent Slot Power: The 13 PCIe slots are grouped into two distinct zones; each slot can be enhanced for better signal and more stable voltage.


• 5 x Power Sync: Supports up to 5 power supply to deliver power for your motherboard and GPUs

Specifications:

PROCESSOR
Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket

CHIPSET
Intel H310 Chipset

MEMORY
2x DDR4 memory slots, support up to 32GB
Supports DDR4 2666/ 2400/ 2133 MHz
Supports non-ECC, un-buffered memory
Supports Dual-Channel mode
Supports Intel Extreme Memory Profile (XMP)

SLOTS
1x PCIe 3.0 x16 slot
12x PCIe 2.0 x1 slots
ONBOARD GRAPHICS
1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
1x HDMI port 1.4, supports a maximum resolution of 4096x216030Hz
*No Display support when using the Processor model with suffix “F”

STORAGE
Intel® H310 Chipset
4x SATA 6Gb/s ports

USB
Inte® H310 Chipset
4x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector)

AUDIO
Realtek ALC887 Codec
7.1-Channel High Definition Audio

LAN
1x Intel I219-V Gigabit LAN controller

INTERNAL CONNECTORS
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
2x 4-pin PCIe power connectors
4x 2-pin PS_ON connectors
4x SATA 6Gb/s connectors
1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x Front panel audio connector
2x Front panel connectors
1x TPM module connector
1x Chassis Intrusion connector
1x Serial port connector
1x Clear CMOS jumper
1x Power button
1x Reset button
1x Clear CMOS button
BACK PANEL PORTS
4x Debug LEDs
1x PS/2 keyboard/ mouse combo port
1x DVI-D port
1x HDMI port
2x USB 3.1 Gen1 Type-A ports
1x LAN (RJ45) port
2x USB 2.0 port
2x USB 2.0 port
3x Audio Jacks
