• Supports 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics Desktop Processors for AM4 socket


• Supports DDR4 Memory, up to 4800+(OC) MHz
  Mystic Light Infinity II: Customize and set up your own color scheme with MSI Mystic Light, combining exclusive mirror reflection to generate the special endless light effects, the GODLIKE makes your system come alive and infinity.


• Dynamic Dashboard: Built-in dynamic panel that indicates the status of GODLIKE and shows off your own personality.


• Lightning Fast Game experience: PCIe 4.0, Triple Lightning Gen4 x4 M.2 with M.2 Shield Frozr, StoreMI, AMD Turbo USB 3.2 Gen2.


• Frozr Heatsink Design: Designed with the patented fan and double ball bearings to provide the best performance for enthusiast gamers and prosumers. Extended Heat-pipe Design: Enlarge the surface of heat dissipation, connecting from VRM heatsink to chipset heatsink.


• Xtreme Audio DAC: Isolated audio with ESS DAC, 2x audio processors & Nahimic to deliver the breathtaking sound quality with 384kHz/32-bit


• Killer xTend: Combine a built-in-switch with wireless extender. Dual Killer fueled LAN & WIFI 6 extender with ultimate traffic prioritization.
  Pre-installed I/O Shielding: Better EMI protection and more convenience for installation

Specifications:

PROCESSOR
Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for Socket AM4

CHIPSET
AMD X570 Chipset

MEMORY
4x DDR4 memory slots, support up to 128GB
3rd Gen AMD Ryzen™ Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 /4533 /4600 /4733 /4800 Mhz by A-XMP OC MODE
2nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000 /3066 /3200 /3466 /3600 Mhz by A-XMP OC MODE

Dual channel
memory architecture

Supports
non-ECC UDIMM memory
ECC UDIMM memory (non-ECC mode)
un-buffered memory

EXPANSION SLOTS
3x PCIe 4.0/3.0 x16 slot (PCI_E1~3)1
3rd Gen AMD Ryzen™ support PCIe 4.0 x16/x0/x0, x8/x0/x8, x8/x4/x4 mode
2nd Gen AMD Ryzen™ support PCIe 3.0x16/x0/x0, x8/x0/x8, x8/x4/x4 mode
Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0 x8/x0/x0 mode
1x PCIe 4.0/3.0 x16 slot (PCI_E4, supports x4 mode)
The speeds may vary for different devices
MULTI-GPU

Supports
2-Way NVIDIA SLI Technology
4-Way AMD CrossFire Technology

STORAGE
AMD X570 Chipset
4x SATA 6Gb/s ports (SATA1-SATA4)
3x M.2 slots (Key M)1
M2_1 slot (from AMD® X570 Chipset) supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™) or 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) and SATA 6Gb/s 2242/ 2260/ 2280/ 22110 storage devices
M2_2 slot (from AMD® X570 Chipset) supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™) or 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) and SATA 6Gb/s 2242/ 2260/ 2280 storage devices
M2_3 slot (from AMD® Processor) supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™) or PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) 2242/ 2260/ 2280/ 22110 storage devices
ASMedia ASM1061
2x SATA 6Gb/s ports (SATA5, SATA6)
The speeds may vary for different devices

RAID
AMD X570 Chipset
Supports RAID 0, RAID 1 and RAID 10

USB
AMD X570 Chipset
3x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) ports (2 Type-A ports on the back panel, 1 Type-C internal connectors)
4x USB 3.2 Gen1 (SuperSpeed USB) ports through the internal USB connectors
4x USB 2.0 (High-speed USB) ports through the internal USB connectors

AMD Processor
2x USB 3.2 Gen2 (3rd Gen AMD Ryzen™) or USB 3.2 Gen1 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) Type-A and Type-C port on the back panel
2x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel

AUDIO
2x Realtek® ALC1220 Codec
7.1-Channel High Definition Audio
Supports Optical S/PDIF output
ESS® E9018 Codec
Supports 6.3mm Gold-plated stereo headphone out

LAN
1x Killer™ E2600 Gigabit LAN Controller
1x Killer™ E3000 2.5 Gbps LAN Controller

WIFI & BLUETOOTH
Killer™ Wi-Fi 6 AX1650 Chipset
The Wireless module is pre-install in the M2_4 (Key-E) slot
Supports Wi-Fi 802.11 a/b/g/n/ac/ax, dual band (2.4GHz, 5GHz) up to 2.4 Gbps speed
Supports Bluetooth® 5

INTERNAL CONNECTORS
1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connectors
6x SATA 6Gb/s connectors
3x M.2 slots (M-Key)
1x USB 3.2 Gen2 Type-C port
2x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x 4-pin CPU fan connector
1x 4-pin Water Pump connector
7x 4-pin system fan connectors
1x 3-pin Water Flow connector
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
2x 2-pin Thermal Sensors connectors
1x 4-pin RGB LED connector
2x 3-pin RAINBOW LED connectors
1x 3-pin CORSAIR LED connector

BACK PANEL PORTS
Clear CMOS Button
Wi-Fi /Bluetooth Antenna Connectors
PS/2 GAMING Device Port
Killer 2.5G + Killer Gigabit LAN
HD Audio Connectors
Flash BIOS Button
USB 3.2 Gen1 Ports
USB 3.2 Gen2 Ports Type-A+C
USB 3.2 Gen2 Ports
6.3mm headphone
Optical S/PDIF-Out
MEG X570 GODLIKE

DIMENSIONS
12 in. x 10.7 in. (30.5 cm x 27.2 cm)

E-ATX Form Factor

MOUNTING
9 mounting holes

OPERATING SYSTEM
Windows 10 64-bit
