MSI MEG X399 CREATION AMD DDR4 Motherboard
Buy MSI MEG X399 CREATION AMD DDR4 Motherboard at Best Prices!
- Supports 1st and 2nd Gen AMD® RYZEN™ THREADRIPPER™ Series Processors
Support 8 DIMMs, Quad Channel DDR4 3600+ (OC)
Maximum Power: 19 phases digital power with heat-pipe heatsink design - Maximum Temperature Control: Full fan control with 10 PWM fan headers and 3 dedicated thermal sensors
Maximum Storage: 7 x Turbo M.2 with M.2 XPANDER-AERO and AMD StoreMI technology - Maximum Data Transfer: Dual Gigabit LAN with Dual-band Wireless-AC and bandwidth management
- M.2 Shield FROZR: Strengthened built-in M.2 thermal solution. Keeps M.2 safer and faster
- Core Boost: With premium layout and full digital power design to support more cores and provide better performance
- Dual 8 Pin Power Supply: By providing dual 8 pin connectors to ensure adequate power supply to unleash ultimate multi-core CPU performance
- MYSTIC LIGHT: 16.8 milliom colors / 17 effects controlled in one click. MYSTIC LIGHT EXTENSION support both RGB and RAINBOW LED strip
Lightning Fast Transfer Experience: 3x TURBO M.2 with Shield FROZR, AMD Turbo USB 3.1
Audio Boost 4 with NAHIMIC: Reward your ears with studio grade sound quality
DDR4 Boost with Steel Armor: Fully isolated, shielded and optimized DDR4 PCB design to give your DDR4 memory a performance boost - MULTI-GPU: With STEEL ARMOR PCI-E slots. Supports 3-Way NVIDIA SLI™ & 3-Way AMD Crossfire™
- certified for Windows 10
PROCESSOR
Supports 1st and 2nd Gen AMD RYZEN THREADRIPPER Series Processors for SocketTR4
CHIPSET
AMD X399 Chipset
MEMORY
8 x DDR4 memory slots, support up to 128GB
Supports DDR4 3600+(OC)/ 3466(OC)/ 3333(OC)/ 3200(OC)/ 3066(OC)/ 2933(OC)/ 2800(OC)/ 2667(OC)/ 2400/ 2133 MHz
Quad channel memory architecture
Supports ECC UDIMM memory
SLOTS
2x PCIe 3.0 x16 slots (PCIE_1, PCIE_4)
2x PCIe 3.0 x8 slots (PCIE_3, PCIE_5)
1x PCIE 2.0 x1 Slot
MULTI-GPU
Supports 3-Way NVIDIA SLI™ Technology
Supports 3-Way AMD CrossFire™ Technology
STORAGE
AMD X399 Chipset
8 x SATA 6Gb/s ports
AMD CPU
3 x M.2 ports (Key M)
Supports up to PCIe 3.0 x4 and SATA 6Gb/s
M2_1, M2_3 slots support 2242/ 2260 /2280 storage devices
M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices
RAID
AMD X399 Chipset
Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
USB
ASMedia ASM3142 Chipset
1x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port available through the internal USB connector
AMD X399 Chipset
1x USB 3.1 Gen1 (SuperSpeed USB) Type-A port on the back panel
1x USB 3.1 Gen1 (SuperSpeed USB) Type-C port on the back panel
4x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connectors
4x USB 2.0 (High-speed USB) ports available through the internal USB connectors
AMD CPU
8x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel
AUDIO
Realtek ALC1220 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN
2 x Intel® I211AT Gigabit LAN controllers
WIFI & BLUETOOTH
Intel Wireless-AC 9260 card
Supports Wi-Fi 802.11 ac, 2x2, Dual Band, (2.4GHz, 5GHz) up to 1.73 Gbps speed.
Supports Bluetooth 5
INTERNAL CONNECTORS
1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connector
1x flat 4-pin ATX 12V power connector
8x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
1x USB 3.1 Gen2 Type-C port
1x 4-pin CPU fan connector
1x 4-pin Water Pump connector
5x 4-pin system fan connectors
3x 4-pin extend fan connectors
2x Front panel connectors
1x Front panel audio connector
2x 5050 RGB LED strip 12V connector (JRGB1~2)
1x WS2812B Individually Addressable RGB LED strip 5V connector (JRAINBOW1)
1x CORSAIR connector (JCORSAIR1)
1x TPM module connector
3x 2-pin Thermal Sensors connectors
| Product Name | MSI MEG X399 CREATION AMD DDR4 Motherboard |
|---|---|
| Weight | 0.45 Kg |
| Operating System | Windows 10 64-bit |
| CPU Support (Max) | RYZEN THREADRIPPERTM Series Processors |
| DDR Memory | Quad Channel memory supports 2133/2400/2667(nonOC-by JEDEC)/2667(OC)/2800(OC)/2933(OC)/3066(OC)/3200(OC)/3333(OC)/3466(OC)/3600+(OC) |
| Socket | SocketTR4 |
| Manufacturer | MSI |
| Color | Black |
| Country of Origin | United Arab Emirates |
