ABB 10 kVA PowerValue 11/31 T B2 Single Phase UPS Reliable Backup Solution
Simple to install and with a small footprint, the PowerValue 11/31 T produces stable, regulated, transient-free, pure sine wave AC power with extremely tight output voltage regulation.
PRODUCT OVERVIEW
ABB 31‐10KVA B2 Powervalue Tower
Simple to install and with a small footprint, the PowerValue 11/31 T produces stable, regulated, transient-free, pure sine wave AC power with extremely tight output voltage regulation.
Energy savings thanks to 93% efficiency 97% efficiency in ECO mode
Low harmonic distortions (< 5% THDi) and active power factor correction (0.99 input PF) eliminate interference from other equipment in the network Paralleling and redundancy capability (up to 4 units in parallel) increases system capacity and availability Integrated automatic and manual bypass simplifies maintenance and reduces the need for external switchgears. Frequency converter operation to convert 50 to/from 60 Hz. Compact solution that can achieve 5-16 min runtime with internal batteries The same model supports different wiring schemes: three-phase and single-phase input as well as single and dual input feed.
Brief Specifications
- PowerValue 11/31 T 10 kVA
- UPS frame rated power: 9 kW
- Batteries: internal backup—single string 5 mins, 2 strings 16 mins
- Parallel configuration: up to 4 units
- Dimensions (WxHxD): 350x890x715 mm
- Weight without batteries (kg): 65
| Product Name | ABB 10 kVA PowerValue 11/31 T B2 Single Phase UPS Reliable Backup Solution |
|---|---|
| Output Power | 10.0kVA/ 10000VA |
| Output Voltage | 0.9 |
| Input Frequency | 55 - 65 Hz for 60 Hz system |
| Input Voltage Range | 1ph + N: 220 / 230 / 240 VAC |
| Interface Ports | LCD, RS-232, SNMP slot, USB |
| Control Panel | LCD Display |
| Battery Type | VRLA, vented lead-acid |
| Recharge Time | Approx. 12‑18 min @ full load (varies with battery condition and configuration) |
| Approvals | Network interface (SNMP card), dry- contact card (AS400) |
| Dimensions | ~350 × 890 × 715 mm |
| Weight | 178.000000 |
| Shipping Weight | ~202 kg (approx.) |
| Manufacturer | ABB |
| Color | Black |
| Country of Origin | United Arab Emirates |
