PRODUCT OVERVIEW

Designed for permanent installation, the AKG GN series goosenecks are designed in 3 fixed lengths. The GN15 measures approximately 6 inches in length, the GN30 is 12 inches and the GN50 is 20 inches. The goosenecks are completely compatible with AKG CK series microphone capsule modules.

This model features a 5-pin XLR male output and large LED ring for enhanced visibility. The LED ring indicates an active microphone and the 5-pin XLR connection will carry audio signal as well as power to the LED ring from a separate power supply, e.g., a Logic out from the AS 16 x 12 automatic mixer. The goosenecks feature a bass roll-off switch and quiet gooseneck positioning. The bass roll-off filter eliminates low frequency noise caused by ambiance, ground and structure noise.

5-pin XLR and Large LED Ring

A 5-pin XLR male output and large LED ring are provided. The LED ring indicates an active microphone and the 5-pin XLR connection will carry audio signal as well as power to the LED ring from a separate power supply.

Proven reliability

The GN E 5Pin high-performance gooseneck modules for fixed and mobile installation provide a five-pin XLR connector that allows the audio signal and the control voltage for the LED ring to be fed separately. Thus, the LED ring can be activated remotely by, for example, a logic output from any automatic mixer. The LED ring is extra-large for enhanced visibility. The DAM Series GN E five-pin gooseneck modules are available in three different lengths: 15cm (6in), 30cm (12in) and 50cm (20in). The gooseneck module fits all DAM Series capsules, CK31, CK32, CK33, CK47 and CK80, via highly reliable contacts.

Features

• The GN series goosenecks are completely compatible with the CK series modular microphone capsules.
• Low frequency roll-off filter switch reduces low frequency noise caused by ambiance, structure noise, etc.
• The gooseneck provides silent microphone positioning.
