Avalon 305m Cat6 UTP 23 AWG Cable Roll
Avalon Cables are the best twisted-pair cables in the market for transmitting data over local area Networks LANs. As streaming video and multimedia over LAN are gaining popularity, users demand faster data transmission and reduced waiting time.
PRODUCT OVERVIEW
CAT.6 UTP LSZH Cable - 305 Meter - Grey
Avalon Cables are the best twisted-pair cables in the market for transmitting data over local area Networks LANs. As streaming video and multimedia over LAN are gaining popularity, users demand faster data transmission and reduced waiting time. These Cables are ideal for simple, cost-effective and high-speed transmission performance. They support a higher signal-to-noise ratio, providing better reliability for current applications and higher data rates for future applications.
Applications
- Horizontal Distribution and Backbone Cabling
- 4/16 Mbps Token Ring(IEEE 802.5)
- 10/100/1000 Base (IEEE 802.3)
- 155Mbps ATM
- 100 Mbps TP-PMD
- Analogue Voice, ISDN, ADSL
Standards
- ISO/IEC11801:2011(Ed. 2.2)
- ANSI/TIA/EIA-568-C.2
- EN 50173-1:2011
- EN 50173-2:2007 including amendment A1:2010
- IEC61935-2:2010(Ed.3.0) (transmission requirements)
- Fire Standards –IEC 60754-2 and IEC 61034
| Product Name | Avalon 305m Cat6 UTP 23 AWG Cable Roll |
|---|---|
| Weight | 4.535924 |
| Type | 4 Pairs Unshielded Twisted Pair (UTP) Category 6 Cable |
| Lengt | 305 Meters |
| Pulling Strength | 110N |
| Min Bend Radius | 4 times outer diameter |
| Cores | 4 |
| Fire Resistance | LSZH Cable meets IEC 60754-2 & IEC61034 |
| Operating Temperature | -20℃ to +75℃ |
| Manufacturer | Avalon |
| Color | Grey |
| Country of Origin | China |
Product Datasheet
