PRODUCT OVERVIEW

Avalon FTTH Termination box 2 Port. The Smaller size fiber optic terminal box is used for fiber optic distribution and organization. Our typical fiber terminal boxes come with 4, 8 and 16 ports. We have different FTTH termination boxes which can be used for indoor or outdoor terminations and distribution. The fiber optic boxes are made of cold rolling steel and the surface of the box use the technique of dim blowing plastic. This type fiber optic box is available with variety of adaptor cutouts. Additional splice trays can be stacked on top to increase capacity. Each splice tray can install up to 24 single fiber splice protection sleeves (with diameter of 2.3mm) or 6 ribbon splice protection sleeves. Splice trays can be opened individually and removed from the box. Excess length of cables/pigtails is stored in reels on the front panel

Features

• Ability to allow cables to enter from rear or bottom of the unit.
• All fibers are positively managed to maintain a 30mm minimum bend radius.
• Optional Removable rear entry cable management.
• Flip tray to allow access to connect tails and cable entry
• Compact, low profile, wall mounted unit used for small and large business premises.
• Removable cover for easy access.
• Tamper proof cover security screws available as an option
• Unit manufactured from fire resistant UL94-V0 rated material.
• Patch cord exit unit on bottom face and are protected by two protection covers.
• Standard colour white. Other colours available on request
