Cisco GLC-LH-SMD= 1000BASE-LX/LH SFP Transceiver, 1Gbps, 1310nm, Single-Mode Fiber
Call For The Best Price
Contact our sales team today for exclusive pricing and product availability.
Call Now: +971-4-3360300Key Features Of The GLC-LH-SMD=
-
1 Gbps Gigabit Ethernet connectivity
-
Supports 1000BASE-LX/LH
-
1310 nm optical wavelength
-
Up to 10 km reach over single-mode fiber
Cisco GLC-LH-SMD= 1000BASE-LX/LH SFP Transceiver
Reliable 1 Gigabit Ethernet optical transceiver designed for long-distance fiber connectivity, supporting 1000BASE-LX/LH, 1310 nm operation and distances of up to 10 km over single-mode fiber.
The Cisco GLC-LH-SMD= is a Gigabit Ethernet SFP transceiver designed to provide reliable optical connectivity for compatible Cisco networking equipment. Supporting the 1000BASE-LX/LH standard, this SFP operates at a nominal wavelength of 1310 nm and provides a maximum transmission distance of up to 10 km when deployed over compatible single-mode fiber.
The compact SFP form factor makes the GLC-LH-SMD= suitable for switches, routers and other compatible networking platforms that require Gigabit Ethernet fiber connectivity. The transceiver also supports Digital Optical Monitoring (DOM) on compatible platforms, allowing optical operating parameters to be monitored by the network device.
Key Features
Provides Gigabit Ethernet connectivity using the 1000BASE-LX/LH optical standard.
Supports high-speed Gigabit Ethernet data transmission for network access, distribution and backbone connections.
Supports transmission distances of up to 10 km over compatible single-mode fiber infrastructure.
Uses a nominal 1310 nm optical wavelength for fiber-based network connectivity.
Uses a Duplex LC/PC optical connector for fiber connectivity.
Supports DOM on compatible Cisco platforms for monitoring optical transceiver parameters.
Provides a compact pluggable interface for compatible Cisco networking equipment.
Allows supported networking devices to add or replace the optical module without requiring the entire platform to be replaced.
Network Applications
The Cisco GLC-LH-SMD= can be used in a range of Gigabit Ethernet network environments where optical fiber connectivity is required.
- Enterprise network infrastructure
- Campus network connectivity
- Gigabit Ethernet backbone links
- Switch-to-switch fiber connections
- Router-to-switch connectivity
- Building-to-building network links
- Network distribution layers
- Data center fiber connections
- Long-distance LAN infrastructure
Installation & Compatibility
The GLC-LH-SMD= is designed for use with compatible Cisco networking platforms featuring an SFP interface and support for 1000BASE-LX/LH optics. The module can be installed in a compatible SFP slot and connected to the appropriate fiber infrastructure using Duplex LC connectors.
Before deployment, verify the transceiver compatibility list and supported hardware and software versions for the specific Cisco switch, router or networking platform.
Why Choose Cisco GLC-LH-SMD=?
The Cisco GLC-LH-SMD= provides a practical solution for Gigabit Ethernet networks requiring fiber-based connectivity over extended distances. With 1000BASE-LX/LH support, 1310 nm optical operation, Duplex LC connectivity and up to 10 km reach over single-mode fiber, it is suitable for enterprise, campus and network infrastructure deployments.
Its compact SFP form factor also provides deployment flexibility across compatible Cisco networking platforms while DOM capability can assist with optical link monitoring and troubleshooting.
Cisco GLC-LH-SMD= 1000BASE-LX/LH SFP Transceiver
The Cisco GLC-LH-SMD= is a 1 Gigabit Ethernet SFP transceiver designed for reliable fiber connectivity. Supporting 1000BASE-LX/LH, 1310 nm operation and up to 10 km over single-mode fiber, it is suitable for compatible Cisco switches, routers and network infrastructure.
| Product Name | Cisco GLC-LH-SMD= 1000BASE-LX/LH SFP Transceiver, 1Gbps, 1310nm, Single-Mode Fiber |
|---|---|
| Weight | 0.800000 |
| Interface | SFP / 1000BASE-LX/LH |
| Power Source | 3.3 V DC / SFP Host Interface |
| Working Environment: | Commercial |
| Power Consumption | Up to 1 W |
| Unit Weight (KG): | 0.08 kg |
| Manufacturer | Cisco |
| Color | Silver |
| Country of Origin | United States |
