JBL Control 24CT Micro 4.5" 2-Way 30W Low-Profile Ceiling Speaker (Each)
SKU
CONTROL 24CT MICRO
$151
$144
Limited Stock - Running Out Quickly
Pay as low as per month in 4 equal installments interest free
Pay as low as per month in 4 equal installments interest free
We also accept
Quick Overview
- Compact Ceiling Speaker
- For Background and Foreground Music
- For Paging Sound Systems
- Speakers: 4.5" Woofer & 1/2" Tweeter
- Frequency Response: 85 Hz to 25 kHz
- 150° Coverage
- 70/100V Transformer Taps
- Shallow 4" Depth
PRODUCT OVERVIEW
Background Music Ceiling Loudspeaker
The full, high-quality sound of the compact JBL Control 24CT Micro Ceiling Speaker System is ideal for medium-volume paging and background music applications, including restaurants, professional offices, and retail. Installation is possible without ceiling access, and the built-in voltage transformer allows for additional speakers and system flexibility.
Use the Control 24CT Micro with other high/mid-response control contractor systems to achieve a more flexible system capable of mixing and matching zones without separate equalization. Low frequencies may be augmented using a Control Contractor subwoofer.
|
|
|
Features
- Extremely wide 150° coverage.
- Smooth frequency response.
- Components:
4.5 in (115 mm) woofer, injection-molded graphite cone with butyl rubber surround.
.5 in (12 mm) polycarbonate tweeter for extended response. - Control 24C Micro is 8 ohms and handles 15 W.
- Shallow 4 in (100 mm) depth.
- Packaged with a grille, back can, and tile rails for fast installation and easy dealer stocking.
| Product Name | JBL Control 24CT Micro 4.5" 2-Way 30W Low-Profile Ceiling Speaker (Each) |
|---|---|
| Weight | 1.600000 |
| Frequency Response | 85 Hz to 25 kHz |
| Frequency Range | 85 Hz – 25 kHz |
| Power Capacity | 30W Continuous Program Power 15W Continuous Pink Noise |
| Maximum SPL | Control 24C Micro: 98 dB @ 1 m (3.3 ft) Control 24CT Micro: 94 dB @ 1 m (3.3 ft), 9W tap |
| Impedance | 8 ohms7.1 ohms |
| Sensitivity (SPL / 1 W @ 1 m) | 86 dB (100 Hz - 10 kHz) |
| Enclosure | Backcan : Formed steel Baffle/Rim: Medium impact polystyrene, fire rated UL94V-O Secondary Attachment Point: Included |
| Mounting | Ceiling |
| Dimensions | 7.7 x 4.2" / 19.5 x 10.6 cm (4.1" / 10.5 cm from Front of Ceiling Tile to Back of Backcan) |
| Manufacturer | JBL |
| Color | White |
| Country of Origin | United States |
Write Your Own Review
Product Datasheet
