JBL PD595 15" Horn-Loaded Full-Range Loudspeaker System 90° x 50° White (Single)
Short Description
-
15-inch horn-loaded full-range loudspeaker system
-
90° x 50° controlled coverage pattern
-
High-output performance with excellent pattern control
-
Rotatable Progressive Transition™ waveguide
-
Passive and bi-amp selectable operation
-
50 Hz–20 kHz frequency range
-
104 dB system sensitivity
JBL PD595 15-Inch Horn-Loaded Full-Range Loudspeaker System 90° x 50° White
Professional 15-inch horn-loaded full-range loudspeaker with 90° x 50° rotatable coverage, high-output performance and excellent pattern control for professional sound reinforcement.
Product Overview
The JBL PD595-WH is a professional 15-inch horn-loaded full-range loudspeaker system designed for applications requiring high acoustic output, excellent pattern control and reliable sound reinforcement performance.
The system features a 380 mm (15-inch) horn-loaded low-frequency driver combined with a high-frequency compression driver and Progressive Transition™ waveguide technology. The waveguide provides a controlled 90° x 50° coverage pattern and can be rotated to support either horizontal or vertical cabinet orientation.
With a frequency range of 50 Hz to 20 kHz and high system sensitivity, the PD595 delivers powerful and intelligible sound reproduction for professional music, speech and sound reinforcement applications.
Key Features
15-Inch Horn-Loaded Driver
380 mm (15-inch) horn-loaded low-frequency driver provides high sensitivity and powerful acoustic output.
90° x 50° Coverage
Progressive Transition™ waveguide provides controlled horizontal and vertical sound dispersion.
Rotatable Waveguide
The waveguide can be rotated to support horizontal or vertical cabinet installation.
High Output Performance
Engineered for professional applications requiring high acoustic output and excellent directivity.
Bi-Amp / Passive Operation
Selectable crossover modes provide flexibility when configuring professional sound reinforcement systems.
White Finish
The PD595-WH configuration features a professional white finish for visually demanding installations.
Professional Audio Performance
The JBL PD595 is engineered for professional sound reinforcement applications where high output, controlled directivity and consistent frequency response are important.
Its horn-loaded architecture provides efficient acoustic performance while the Progressive Transition™ waveguide helps maintain controlled sound distribution across the intended listening area.
The PD595 can be used as a full-range system for music and speech applications or integrated with professional subwoofers when extended low-frequency performance is required.
Flexible Installation & System Configuration
The rotatable waveguide allows the JBL PD595 to operate in either horizontal or vertical cabinet orientation. Selectable bi-amp and passive crossover modes provide additional flexibility when integrating the loudspeaker into professional sound systems.
Technical Specifications
| Brand | JBL Professional |
|---|---|
| Model | PD595-WH |
| Speaker Type | 15-Inch Horn-Loaded Full-Range Loudspeaker System |
| Low-Frequency Driver | 2031H 380 mm (15-Inch) Driver |
| High-Frequency Driver | JBL 2432H 1.5-Inch Exit Compression Driver |
| Coverage Pattern | 90° x 50° |
| Frequency Range (-10 dB) | 50 Hz – 20 kHz |
| Frequency Response (±3 dB) | 90 Hz – 16 kHz |
| System Sensitivity | 104 dB SPL (1W @ 1m) |
| Maximum SPL | Up to 139 dB Peak |
| System Power Rating | 500W / 2 Hours, 300W / 100 Hours (Passive Mode) |
| Nominal Impedance | 8 Ohms |
| Passive Crossover | 1.3 kHz |
| Crossover Modes | Bi-Amp / Passive Switchable |
| Enclosure | 18 mm 11-Ply Finnish Birch Plywood |
| Finish | White DuraFlex™ Finish |
| Suspension | 20 M10 Threaded Suspension Points |
| Dimensions | 782 x 783 x 670 mm |
| Net Weight | 69 kg |
| Color | White |
| Quantity | Single Loudspeaker |
Recommended Applications
Why Choose JBL PD595-WH?
The JBL PD595-WH combines JBL professional loudspeaker engineering with a powerful 15-inch horn-loaded design, controlled 90° x 50° coverage and flexible installation options. Its rotatable waveguide and selectable crossover modes make it a versatile solution for demanding professional sound reinforcement installations.
| Product Name | JBL PD595 15" Horn-Loaded Full-Range Loudspeaker System 90° x 50° White (Single) |
|---|---|
| Weight | 69.000000 |
| Frequency Response | 90Hz to 16kHz |
| Frequency Range | 50Hz to 20kHz |
| Maximum SPL | Bi-amp: LF: 133 cont (139 peak) HF: 131 cont (137 peak) Passive: 131 cont (137 peak) |
| Impedance | 8 ohms |
| Sensitivity (SPL / 1 W @ 1 m) | 104 dB SPL |
| Enclosure | Trapezoidal with 10 degree side angles, 18 mm exterior grade 11-ply Finnish birch plywood. |
| Dimensions | 782.0 x 783.0 x 670.0 mm (30.8 x 30.8 x 26.4 in) |
| Manufacturer | JBL |
| Color | White |
| Country of Origin | United States |
