LD Systems CURV 500 I AMP 4-Channel Class D Installation Amplifier
PRODUCT OVERVIEW
Purpose-designed for CURV 500® installations the iAMP® is a low-profile 4-channel Class D rackmount amplifier with high-efficiency switch mode power supply and 10 Hz – 22 kHz frequency response. Sporting DSP control with presets for various satellite and subwoofer configurations, delay and parametric EQ each channel delivers 240 watts RMS at 4 ohms with less than 0.01% THD.
Operating the iAMP® is simple and intuitive with just a single push encoder and easily readable high-contrast OLED display. It features a soft start circuit, DC, overcurrent, thermal and short circuit protection plus a temperature controlled low- noise fan. Input is on balanced XLR and terminal block connectors. The iAMP® is capable of driving up to six CURV 500® satellites or one CURV500ISUB subwoofer per channel providing terminal block and speakON-compatible output connectors.
- 4 channels with DSP control
- Purpose-designed for CURV 500® installations
- Low-profile 1U 19" rackmount construction
- Drives up to six CURV 500® satellites or one CURV 500® ISUB subwoofer perchannel
- Single push encoder operation
- High-contrast OLED display
- Temperature controlled low-noise fan
- High-efficiency switch mode power supply
- Only 6.8 kg
| Product Name | LD Systems CURV 500 I AMP 4-Channel Class D Installation Amplifier |
|---|---|
| Weight | 6.80 Kg |
| Frequency Response | 10 - 22000 Hz |
| Power Capacity | 1100W |
| Dimensions | Width 482 mm Height 44 mm Depth 420 mm |
| Manufacturer | LD Systems |
| Color | Black |
| Country of Origin | United States |
