Soundcraft ViO/D21 AES In/Out Packed Tested Spare Vi Option Card

PRODUCT OVERVIEW

Compatibility:

The RS2422SP is equipped with AES/EBU inputs and outputs on standard 25-pin D-type female connectors. Its digital interface supports flexible signal integration while maintaining the reliability and signal integrity expected in professional live sound, broadcast, theatre, touring, and installed audio environments.

3G SDI CARD

The 3G SDI card can de-embed up to 16 audio channels from an SDI (Serial Digital Interface) stream, and re-embed them (Embedder/ DeEmbedder card only) back on to the stream for onward transmission in a broadcast environment, saving high costs of external units and, of course, weight. These channels may be patched in to any input as usual.

Key Features

• Brand: Soundcraft

• Model: RS2422SP

• Product Type: ViO/D21 AES/EBU In/Out Option Card

• Digital I/O: 16-channel AES/EBU I/O

• Input Sample Rate Converters: Included on inputs

• SFC Bypass: Input SFCs can be individually bypassed

• Output Dither: Selectable per AES/EBU output

• Dither Options: 24-bit, 20-bit, 18-bit or 16-bit

• Configuration: Internal jumper settings

• Connectors: Standard 25-pin D-type female connectors

• SKU / Part Number: RS2422SP

• Condition: Packed and tested spare
