Soundcraft ViO/D21 Mic In Packed Tested Spare Vi Option Card

PRODUCT OVERVIEW

Compatibility:

The Soundcraft RS2423SP ViO/D21 Mic In Option Card is a professional analogue microphone/line input expansion card designed for compatible Soundcraft Vi Series mixing systems. It provides four electronically balanced microphone/line inputs, making it suitable for professional live sound, broadcast, theatre, touring, recording, and installed audio applications.

AES/EBU CARD

AES/EBU input/ output card with 16 Ch I/O. With input SFCs only. Input SFCs can be bypassed individually. Output dither is selectable for every AES/EBU output from 24 bit, 20 bit, 18 bit or 16 bit. Settings are made with jumpers. Inputs and outputs on standard 25-pin D-type connectors (female).

Key Features

• Brand: Soundcraft

• Model: RS2423SP

• Product Type: ViO/D21 Mic In Option Card

• Input Channels: 4 analogue microphone/line inputs

• Input Type: Electronically balanced

• A/D Conversion: 24-bit Delta-Sigma

• Sampling Rate: 48 kHz

• Gain Adjustment: 1 dB steps

• Low-Cut Filter: Supported

• Phantom Power: 48V, software controlled

• Signal Indicator: Green signal-present LED per channel

• Phantom Indicator: Yellow phantom-power LED per channel

• Connector: Standard 25-pin D-type female

• SKU / Part Number: RS2423SP

• Condition: Packed and tested spare
