GW INSTEK GOM-804 D.C Milli-Ohm Meter
Actual Stock Can Be Confirmed After Placing the Order.
SKU
GOM-804
AED 2,496
AED 2,377
Pay 4 interest-free payments of AED 421.00.Learn more
The GOM-805 also includes various drive modes and Dry circuit for contact resistance measurement applications. More features, including 20 sets of panel setting memory and many external control interface such as RS-232C, USB, Handler/Scan/EXT IO or GPIB (option), greatly elevate GOM-804/805 milliohm meter’s convenience on practical applications.
PRODUCT OVERVIEW
GOM-804/805 feature 3.5-inch TFT display, maximum 50,000 counts measurement display, the rapid sampling rate of 60 readings per second, optimum 0.05% measurement precision, four wire measurement method as well as the temperature measurement and temperature compensation measurement function to meet the requirement of low resistance measurement application. The GOM-805 also includes various drive modes and Dry circuit for contact resistance measurement applications. More features, including 20 sets of panel setting memory and many external control interface such as RS-232C, USB, Handler/Scan/EXT IO or GPIB (option), greatly elevate GOM-804/805 milliohm meter’s convenience on practical applications.
GOM-804/805 adopt 3.5-inch color LCD to enhance the clarity of measurement results and to provide display for related setting criteria that tremendously brings up the completeness of test information. Additionally, GOM-804/805, with the optimum 0.05% precision, augment the measurement speed to 60 sampling rate per second and maintain the display digits of five instead of four despite of different speed selections. Furthermore, the independent functionality keys and direction keys together increase the operational convenience which allows users to complete their measurement tasks with intuitive convenience and speed.
With respect to connecting the external control, GOM-804/805 provide a D-sub 25-pin combined interface to execute, according to the functionalities, Handler, Scan or EXT IO for respectively connecting to a sorting machine; connecting to an external on-off switch, and directly conducting external trigger control. For remote control and measurement result retrieval requirements, GOM-804/805 also provide various interface selections such as RS-232C, USB, and GPIB (GOM-804(option)/GOM-805(standard) interface. Furthermore, the control commands are compatible to that of GOM-802 that saves time in adjusting programs while switching from the old model to the new model.
To sum up, GOM-804 evolves from GOM-802 platform with more advanced functionalities and specifications, including display digits, measurement speed and standard interface (RS-232C/USB). With all the capabilities of GOM-804, GOM-805 augments itself with new measurement abilities (Dry circuit and various drive modes) to meet the requirements of broader low resistance measurement applications.
Features
- 50,000 counts
- 3.5” (320 x 240) TFT LCD display
- High accuracy of 0.05% precision
- 1Amp test current, 0.1µΩ resolution
- Fast measurement of 60 readings per second
- Four wire resistance measurement
- Temperature compensation measurement function
- Delayed measurement
- 20 sets of panel setting memory
- Dry circuit (GOM-805 only)
- Drive modes (GOM-805) : DC+/DC-, Pulsed, PWM, Zero, Standby
- Drive modes (GOM-804) : DC+, Standby
- Interface: USB device, RS-232C, Handler/Scan/EXT I/O, and GPIB (option)
| Product Name | GW INSTEK GOM-804 D.C Milli-Ohm Meter |
|---|---|
| Weight | 3.99 Kg |
| Power Supply (PoE) | 100...240V AC 50/60Hz |
| Operating Temperature | -50...399.9°C |
| Dimensions | 223x102x283mm |
| Manufacturer | GW INSTEK |
| Color | Black |
| Country of Origin | United States |
